Stainless Steel Material Parts and Bearings
Stainless steel material having excellent corrosion and wear resistance.
Material
| Material | Chemical Components(%) | |||||
|---|---|---|---|---|---|---|
| Fe | Cr | Ni | Mo | C | Other | |
| S01 | Residual Amount | 15～20 | 10～15 | 2～4 | 0.1max. | 2max. |
| S03 | Residual Amount | 15〜20 | 10〜15 | ー | 0.1max. | Si 0.5〜1.0 |
Mechanical characteristics
| Material | Density (g/cm³) |
Apparent Hardness |
Radial Crushing Strength (MPa) |
Tensile Strength (MPa) |
Elongation (%) |
|---|---|---|---|---|---|
| S01 | 6.6 | 70 (HRA) | 900 | 400 | 8.0 |
| S03 | 6.6 | 60 (HRB) | ー | 300 | 3.5 |
The above values are measured values, not guaranteed values.
Please note that the description is subject to change without notice to improve performance.
Stainless Steel Oil-impregnated Sintered Bearings
Solid lubricant "MnS" is added to stainless steel material to provide excellent corrosion resistance and sliding properties.
Material
| Material | Chemical Components(%) | ||||
|---|---|---|---|---|---|
| Fe | Cr | Ni | MnS | Other | |
| S06 | 65〜70 | 15～20 | 10～15 | 1～3 | 1max. |
Physical properties
| Density (g/cm³) | Oil content (Vol.%) |
Radial Crushing Strength(MPa) |
|---|---|---|
| 6.5〜7.0 | 8max. | 150max. |
The above values are measured values, not guaranteed values.
Please note that the description is subject to change without notice to improve performance.
